45HZ-499.9HZ Frequency Converter

1.Model:AF400M-330020
2.Power Rating:20kVA
3.Input Voltage & Frequency: 3 Phase 208-480V, 50-60HZ
4.Output Voltage & Frequency:3 Phase 200,208V,45-499.9HZ
5.Type: Static Frequency Converter, upright-mounted with wheels
6.Ingress Protection Grade: IP21
7.Applications:Avionics maintenance and testing
8.Brand: ACSOON (support OEM)
9.Features: Ensures precise AC voltage(voltage regulation&stability:±1% FS) to avionics with integrated all kinds of protection(Over voltage,over current,over load,over heat), guaranteeing reliable performance

Send Inquiry Download

Product Description

XI'AN JERRYSTAR INSTRUMENT CO., LTD: Your Trusted 45HZ-499.9HZ Frequency Converter Manufacturer

At XI'AN JERRYSTAR INSTRUMENT CO., LTD, we specialize in manufacturing high-quality 45HZ-499.9HZ frequency converters. Our state-of-the-art design and manufacturing processes ensure superior performance and reliability. With ISO 9001 certification and CE approval, we deliver top-notch power solutions for various industries.

Technical Specifications

Feature	Specification
Capacity (Single Phase Output)	1kVA - 200kVA
Capacity (Three Phase Output)	1kVA - 2000kVA
Input Voltage (Single Phase)	110-230VAC ±20%
Input Voltage (Three Phase)	200-440VAC ±20%
Input Frequency	50/60HZ or 40HZ - 70HZ
Output Voltage (Single Phase)	0-300Vac
Output Voltage (Three Phase)	0-520Vac
Output Frequency	50/60/100/200/400HZ or 40-800HZ adjustable
Frequency Stability	≤0.1%
Voltage Stability	±1%
Output VTHD	<3% @ Linear load
Response Time	≤2ms
Power Factor	≥0.8 (Standard), ≥0.9 (12 Pulse Optional)
Overall Efficiency	≥85%
Overload Capacity	125% for 60s, 150% for 30s
Communication Protocol	Modbus RS232 / RS485 (Optional)
Working Temperature	-10℃ to 50℃
Altitude	<1800m

Application Areas

Industrial Automation

Motor control systems

CNC machines

Conveyor belts

Renewable Energy

Wind turbine testing

Solar inverter calibration

Aerospace

Aircraft ground power units

Avionics testing equipment

Research and Development

Laboratory power supplies

Product testing and validation

Manufacturing

Precision machining

Quality control equipment

HVAC Systems

Variable frequency drives

Energy-efficient climate control

Marine Industry

Ship-to-shore power converters

Onboard electrical systems

Oil and Gas

Offshore platform power management

Pipeline monitoring systems

Quality Control

At ACSOON, quality is our creed. We implement rigorous quality control measures:

Strict component selection and inspection
Comprehensive testing at every production stage
Final product performance validation
Continuous improvement based on customer feedback

Why Choose ACSOON 45HZ-499.9HZ Frequency Converters?

R&D Results

Our commitment to innovation has led to several breakthroughs:

Advanced IGBT integration for improved efficiency

Intelligent cooling systems for extended product life

User-friendly interfaces with LCD displays

IoT-enabled remote monitoring capabilities

Qualification Certification

ISO 9001:2015 Certified

CE Marked Products

RoHS Compliant

UL Listed (for specific models)

After-Sales Service

Our commitment doesn't end with the sale:

Comprehensive user manuals and documentation

24/7 technical support

On-site installation and training (where applicable)

Extended warranty options

Packaging and Transportation

We ensure safe delivery of our 45HZ-499.9HZ frequency converters:

Custom-designed packaging for maximum protection

Shock-absorbing materials to prevent transit damage

Clear labeling and handling instructions

Flexible shipping options to meet your needs

Exhibitions

We regularly showcase our products at international trade shows:

Hannover Messe (Germany)
CIIF (China International Industry Fair)
SPS IPC Drives (Italy)
POWER-GEN International (USA)

FAQ

Q1: What's the typical lead time for a custom product?
A: Lead times vary based on specifications, but generally range from 2-6 weeks.

Q2: Do you offer remote monitoring capabilities for your converters?
A: Yes, we offer optional IoT-enabled remote monitoring for real-time performance tracking.

Q3: Are your products suitable for harsh environments?
A: Absolutely. We design our converters to withstand challenging conditions, including high temperatures and dust.

Q4: Can your converters handle input voltage fluctuations?
A: Yes, our converters are designed to handle input voltage variations of ±20%.

Q5: What's the warranty period for your products?
A: We offer a standard 1-year warranty, with options to extend up to 5 years.
