Aviation Test AC Power Supply

1.Output: 0‑300V adjustable, 45‑200Hz adjustable, pure sine wave
2.Power: 1kVA, 2kVA, 3kVA, 5kVA, single‑phase
3.Input: 220V ±15% single‑phase, 50/60Hz
4.Key specs: ±1.5% voltage regulation, THD <3.5%, isolation transformer
5.Applications: Basic lab work, small repair shops, school demos, DIY projects
6.Features: Simple analog controls, overload protection, compact metal case
7.Brand: ACSOON (1‑year warranty, built in Xi’an).

Send Inquiry Download

Product Description

AF400M Static Frequency Converter – Short High-Converting Description

What Static Frequency Converter is designed to solve？

Many aviation and test facilities face the same issues:

Standard 50/60Hz power cannot simulate aircraft 400Hz systems
Rotary converters create noise, vibration, and high maintenance cost
Voltage fluctuation leads to unstable test results
High harmonic distortion affects sensitive avionics equipment
Limited flexibility for single-phase and three-phase testing setups

These problems directly impact testing accuracy, efficiency, and operational safety.

The AF400M provides a stable and controlled 400Hz aircraft power simulation system, ensuring:

Accurate conversion from 50/60Hz to 400Hz
Clean sine wave output for avionics and aerospace systems
Stable voltage regulation within ±1%
Safe isolation between input and output systems
Reliable operation under continuous industrial load

It replaces traditional rotary frequency converters with a more stable and low-maintenance solid-state solution.

Compared with most market alternatives, AF400M offers a more balanced industrial solution: More stable than rotary frequency converters (no mechanical wear) Lower harmonic distortion than many low-cost static converters Wider power range suitable for aviation + industrial testing Better long-term reliability for continuous operation Easier maintenance and lower lifecycle cost While some European and US brands focus on high-end laboratory systems, AF400M is designed for practical aviation ground use with industrial durability and cost efficiency.

ACSOON AF400M is an industrial-grade 400Hz static frequency converter designed for aircraft ground power, aerospace testing, and aviation maintenance applications. It converts standard 50Hz/60Hz utility power into stable 400Hz pure sine wave output with low harmonic distortion and high voltage stability, ensuring reliable performance for sensitive avionics and test equipment.

Built with IGBT technology and isolated transformer design, AF400M delivers clean, regulated AC power with full protection and real-time monitoring, making it a dependable solution for MRO facilities, airports, and aerospace laboratories worldwide.

Item	Specification
Product	AF400M Static Frequency Converter
Output Frequency	400Hz (adjustable 300–500Hz)
Output Voltage	115V / 120V / 200V / 208V / 380V (customizable)
Output Waveform	Pure sine wave
Power Range	1kVA – 60kVA (single-phase), up to 300kVA (three-phase)
Input Voltage	110V–240V single phase / 380V–415V three phase
Input Frequency	50Hz / 60Hz ±15%
Voltage Regulation	±1%
THD	<3% (linear load)
Efficiency	≥85%
Isolation	Built-in transformer
Protection	Over-voltage / Over-current / Overload / Over-temperature
Display	LED real-time V / A / Hz / kW / PF
Cooling	Forced air cooling system
Operating Temperature	-10°C to +45°C

If you need it,Contact us at Email: acpower@acsoonpower.com

Static Frequency Converter Main Features

400Hz pure sine wave output for aviation equipment testing
IGBT-based static frequency conversion (no mechanical parts)
Built-in isolation transformer for load safety and stability
Low harmonic distortion (THD < 3%) for sensitive avionics
Wide input compatibility (50Hz / 60Hz grid systems)
Real-time monitoring of voltage, current, frequency, power
Industrial protection system (OVP / OCP / OTP / SCP)
Designed for continuous operation in harsh industrial environments

✅ Why Choose ACSOON AF400M

Compared with most market alternatives, AF400M offers a more balanced industrial solution:
More stable than rotary frequency converters (no mechanical wear)
Lower harmonic distortion than many low-cost static converters
Wider power range suitable for aviation + industrial testing
Better long-term reliability for continuous operation
Easier maintenance and lower lifecycle cost
While some European and US brands focus on high-end laboratory systems, AF400M is designed for practical aviation ground use with industrial durability and cost efficiency.

AF400M Static Frequency Converter Application Areas

The ACSOON AF400M 400Hz static frequency converter is designed for aviation and aerospace test environments where stable aircraft-grade AC power is required.
It is widely used in:
Aircraft maintenance and MRO ground power supply systems
Aviation electronics and avionics testing benches
Aerospace R&D and laboratory power simulation
Airport ground support equipment (GSE) systems
Military aircraft and defense equipment testing
Shipboard and onboard 400Hz power applications
Transformer, motor and induction equipment testing
In these environments, stable frequency and low distortion are critical for safe and repeatable test results.

ABOUT US

·28,698+ long-term repeat clients globally with stable repeat orders

·19+ years domestic & export manufacturing experience for aviation ground power equipment

·7,000+ sq.m modern production factory

·24/7 customer service:＜30 mins quick response + lifetime after-sales support

·60+ independent patented technologies

·Certified as China National High-Tech Enterprise

·Multiple provincial awards, including Shaanxi AAAAA-Level Credibility Enterprise certification

28,696

Long Standing

Customer

19+

Over 19 years

experience

7,000㎡

Factory Area

30min

7/24H

High-Quality

Efficiency Service

Our Services

Quality Control

Every unit tested – 2 hours at 80% load. Check for overheating.
Output verified – Voltage accuracy at five set points. Record kept.
Isolation test – 2kV between input and output for 1 minute. No breakdown.
Knob cycle – 500 full rotations on each potentiometer. No scratchy spots.

R&D Results

Cost reduction – Replaced digital display with analog meters. Cut cost by 20%.
Transformer – Used a standard toroid instead of custom wound. Still meets specs.
Enclosure – Painted steel instead of powder coat. Same protection, lower cost.
User feedback – Hobbyists wanted bigger knobs. Added large rubberized knobs.

Packaging and Transportation

Shipped from Xi'an – Cardboard box with foam inserts. Fits a courier.
Included – Power cord (1.5m), output cable with universal socket, printed quick start.
Manual – One sheet of paper. Double‑sided. No USB.
Pallet – 8 units per pallet for dealers.

After‑Sales Service

1‑year warranty – Return to Xi'an for repair. Parts and labor.
Spare parts (transformer, fan, meters) kept in Xi'an. Express shipping.
Email support – We answer within one business day. Simple questions only.

Qualification Certification

CE – LVD and EMC tested.
ISO 9001:2015 – Our Xi'an facility.
RoHS – Compliant.

FAQ

Q1: Is this suitable for aircraft maintenance use?
Yes. It is commonly used in MRO environments where 400Hz aircraft power is required.

Q2: Can it simulate aircraft power conditions accurately?
Yes, it provides stable 115V/120V 400Hz output with low harmonic distortion.

Q3: Does it support both single-phase and three-phase output?
Yes, both configurations are available depending on system size.

Q4: What kind of load can it handle?
It is designed for linear and mixed industrial loads with isolated transformer support.

Q5: Is it suitable for continuous operation?
Yes, it is designed for industrial duty cycles with long-term operation in mind.
