Power Supply 115V 400HZ

1.Model:AF400M-330100
2.Power Rating: 100kVA
3.Input Voltage & Frequency: 3 Phase 208V-480V, 60HZ
4.Output Voltage & Frequency: 1 Phase115V,400HZ
5.Type: Static Frequency Converter, upright-mounted with wheels
6.Ingress Protection Grade: IP21
7.Applications:Precision instruments
8.Brand: ACSOON (support OEM)
9.Features:Low harmonic distortion(＜3%),Pure sine wave output,EMC compatible,Compact size, silent operation, and isolated output for sensitive equipment.

Send Inquiry Download

Product Description

Power Supply 115V 400HZ: Precision-Engineered Solutions for Aerospace and Beyond

XI'AN JERRYSTAR INSTRUMENT CO., LTD is a leading manufacturer and supplier of Power supply 115v 400HZ systems. Our expertise in crafting high-quality, reliable power solutions sets us apart in the industry. With over 15 years of experience, we deliver cutting-edge product units that meet the stringent demands of aerospace, defense, and specialized industrial applications.

product-1-1

Why Choose ACSOON Power Supply 115V 400HZ?

Unparalleled Quality: Our product systems are built to last, utilizing premium components and advanced manufacturing techniques.
Customization Capabilities: We offer tailored solutions to meet your specific requirements, from unique connectors to specialized cooling systems.
Compliance Assurance: Our products adhere to strict industry standards, including MIL-STD-704 and DO-160, ensuring seamless integration into your operations.
Global Support: With a worldwide presence, we provide localized technical assistance and efficient logistics.
Innovative Design: Our compact, lightweight units maximize power density without compromising performance.

Technical Specifications

Feature	Specification
Capacity (Single Phase)	1kVA to 200kVA
Capacity (Three Phase)	1kVA to 2000kVA
Input Voltage (Single Phase)	110-230VAC ±20%
Input Voltage (Three Phase)	200-440VAC ±20%
Input Frequency	50/60HZ or 40-70HZ
Output Voltage (Single Phase)	0-300Vac
Output Voltage (Three Phase)	0-520Vac
Output Frequency	50/60/100/200/400HZ or 40-800HZ adjustable
Frequency Stability	≤0.1%
Voltage Stability	±1%
VTHD	<3% @ Linear load
Response Time	≤2ms
Power Factor	≥0.8 (Standard), ≥0.9 (12 Pulse Optional)
Efficiency	≥85%
Overload Capacity	125% for 60s, 150% for 30s
MTBF	30,000H
Operating Temperature	-10°C to 50°C
Altitude	<1800m

Application Areas

Our product solutions are ideal for:

Aerospace:
- Aircraft ground power units
- Avionics testing equipment
- Radar systems
Defense:
- Military vehicle power systems
- Naval ship power converters
- Portable field generators
Medical Imaging:
- MRI machines
- CT scanners
- Advanced diagnostic equipment
Industrial:
- High-precision CNC machines
- Semiconductor manufacturing
- Robotics and automation systems
Research Facilities:
- Particle accelerators
- Wind tunnels
- Environmental test chambers

Quality Control

At ACSOON, quality is our cornerstone. We implement rigorous quality control measures:

100% component inspection
Multiple testing stages throughout production
Burn-in testing for enhanced reliability
Final performance verification under simulated load conditions

product-1-1

R&D Results

Our commitment to innovation has yielded significant advancements:

30% reduction in power supply size and weight
Improved efficiency, now reaching up to 92%
Enhanced EMI/EMC performance for sensitive environments
Intelligent monitoring and remote diagnostics capabilities

product-1-1

Packaging and Transportation

We ensure the safe arrival of your Power supply 115v 400HZ:

Custom-designed shock-absorbing packaging
Climate-controlled shipping containers for sensitive components
Real-time tracking and insurance coverage
Expedited shipping options available

product-1-1

After-Sales Service

Our commitment doesn't end with delivery:

24/7 technical support
Comprehensive warranty coverage
On-site servicing available in select regions
Regular firmware updates and performance optimizations

Qualification Certifications

ACSOON power supplies meet or exceed industry standards:

ISO 9001:2015 certified manufacturing processes
CE marked for European market compliance
UL listed for North American safety standards
MIL-STD-461 for EMC in military applications

product-1-1

Exhibitions

Meet us at these upcoming industry events:

Aerospace & Defense Supplier Summit (Seattle, USA)
DSEI (London, UK)
electronica (Munich, Germany)
China International Aviation & Aerospace Exhibition (Zhuhai, China)

FAQ

Q1: What makes ACSOON's product units stand out?
A1: Our units offer superior stability, compact design, and customization options, backed by extensive industry experience and certifications.

Q2: Can you provide custom frequencies beyond 400HZ?
A2: Yes, we can tailor our power supplies to output frequencies from 40HZ to 800HZ to meet specific requirements.

Q3: What is the typical lead time for a custom productsolution?
A3: Lead times vary based on specifications, but we generally deliver custom solutions within 6-8 weeks.

Q4: Do you offer integration support for OEM applications?
A4: Absolutely. Our engineering team provides comprehensive integration assistance, from design to implementation.

Q5: Are your power supplies suitable for harsh environments?
A5: Yes, we offer ruggedized versions designed to withstand extreme temperatures, vibration, and humidity levels.

Contact Us

Ready to power your critical applications with ACSOON's Power supply 115v 400HZ solutions? Reach out to our expert team at acpower@acsoonpower.com for personalized assistance and quotations.
