Precision Test AC Source

1.Power Capacity: 30kVA (precision test design)
2.Technology: Advanced DSP control with pure sine wave output
3.Input: 3-phase 380VAC ±10%, 50/60Hz auto-ranging
4.Output: 0-300VAC, 45-500Hz programmable
5.Key Applications: Precision instrument testing, product validation, quality certification
6.Key Features: High accuracy output; programmable sequences; low distortion; multiple interfaces
7. Ingress Protection Grade: IP21/54
8. Brand: ACSOON (test certification available)

Send Inquiry Download

Product Description

Precision Test AC Source | Accurate AC Power for Testing

XI'AN JERRYSTAR INSTRUMENT CO., LTD manufactures high-precision precision test AC sources for critical testing and validation applications. Our systems provide exceptionally accurate and clean AC power for precision instrument testing, product certification, and quality validation processes where power quality and stability are essential for reliable test results.

Technical Specifications

Feature	Specification
Capacity (Single Phase Output)	1kVA to 200kVA
Capacity (Three Phase Output)	1kVA to 2000kVA
Input Voltage (Single Phase)	110-230VAC ±20%
Input Voltage (Three Phase)	200-440VAC ±20%
Input Frequency	50/60HZ or 40-70HZ
Output Voltage (Single Phase)	0-300Vac
Output Voltage (Three Phase)	0-520Vac
Output Frequency	50/60/100/200/400HZ or 40-800HZ adjustable
Frequency Stability	≤0.1%
Voltage Stability	±1%
Output VTHD	<3% @ Linear load
Response Time	≤2ms
Overall Efficiency	≥85%
Overload Capacity	125% for 60s, 150% for 30s
Working Temperature	-10°C to 50°C

ACSOON Precision Test AC Source Main Features

Isolated output transformer,suitable for any unbalance loads, each single phase can be used independently
EMC compatible
Compatible with both 50Hz and 60Hz power supply network
Low harmonic distortion
Pure sine wave,sinusoidal output
Completely protection and alarm for over voltage, over current and overheating, etc
Display real-time data:voltage,current,frequency, power / power factor

Why Choose ACSOON Precision Test AC Sources?

ACSOON delivers unmatched accuracy for testing applications:

Test Grade Accuracy: ±0.5% voltage and frequency stability
Clean Power: Low distortion pure sine wave output
Programmable Control: Multi-step test sequences
Advanced Monitoring: Real-time parameter display
Reliable Performance: Consistent test conditions

Application Areas

Our precision test AC sources are essential for:

Precision Instruments: Test equipment calibration
Product Validation: Manufacturing quality testing
Certification Labs: Standards compliance testing
Research Facilities: Experimental test setups
Quality Control: Production line testing
Development Labs: Prototype verification
Service Centers: Equipment performance testing
Educational Labs: Engineering test applications

Details display

Quality Assurance

Each precision test AC source undergoes stringent validation:

Accuracy verification testing
Output stability validation
Distortion measurement
Environmental testing
Performance certification

Technical Features

Our precision test AC source incorporates:

Precision voltage reference
Low distortion circuitry
Programmable test sequences
Multiple interface options
Protection systems

Packaging and Delivery

We ensure precision packaging:

Protective packaging materials
Calibration documentation
Careful handling procedures
Installation support

After-Sales Service

Precision support package includes:

Calibration services
Technical support
Maintenance programs
Training services
Parts availability

Certifications

CE Certification

ISO Certification

FAQ
Q1: What are the key features of precision test AC sources?
A: High accuracy, clean power output, and programmable test sequences.
Q2: How accurate is the output?
A: ±0.5% accuracy for reliable test conditions.
Q3: What test sequences are available?
A: Multi-step programmable sequences for automated testing.
Q4: Can the system be calibrated?
A: Yes, with traceable calibration certification.
Q5: What interfaces are included?
A: Multiple interface options for test system integration.
