Ground Power Unit for Aircraft
2.AC Capacity: 45kVA to 180kVA, three-phase four-wire system
3.DC Capacity: 28.5V 400A to 1000A, aircraft standard voltage
4.Input Supply: 380V-480V, 3-phase, 50Hz/60Hz industrial power
5.Efficiency: ≥93% with advanced IGBT technology
6.Applications: Aircraft maintenance, engine starting, ground testing, hangar operations
7.Features: Military interlock, auto voltage compensation, self-diagnosis system, IP54 protection
8.Brand: ACSOON (aviation power specialist).
- Product Description
Ground Power Unit for Aircraft | Aircraft Ground Power Supply 400Hz & 28VDC
XI'AN JERRYSTAR INSTRUMENT CO., LTD is a specialized manufacturer of advanced Ground Power Unit for Aircraft systems. Our Ground Power Unit for Aircraft provides reliable 400Hz AC and 28VDC power for aircraft ground operations, ensuring safe and efficient power supply during maintenance, testing, and turnaround operations at airports worldwide.
Technical Specifications
| Feature | Specification |
|---|---|
| AC Output | 60kVA, 3 Phase 115V/200V, 400Hz (±0.01%) |
| DC Output | 28VDC, 600A(Customized) (±0.5%) |
| Input Voltage | 380V-480V, 3 phase |
| Frequency | 50HZ/60HZ |
| Emissions | Zero CO2 emissions |
| Operational Mode | Battery-powered or Mains electricity |
Ground Power Unit for Aircraft Main Features
- Auto voltage compensation system, ideal voltage at aircraft connector
- Self diagnose system which would show error code on digital display
- 10 events memory stores
- Pure sine wave, sinusoidal output
- Completely protection and alarm for over voltage, over current and overheating, etc
- Eco-friendly, lower power consumption with high efficiency
- With 28VDC military interlock
Why Choose ACSOON Ground Power Unit for Aircraft?
ACSOON Ground Power Unit for Aircraft systems are engineered to meet the rigorous demands of aviation ground operations:
Dual Power Output: Simultaneous 400Hz AC and 28VDC supply for comprehensive aircraft support
Military Standards Compliance: Meets MIL-STD-704F and ISO6858 aircraft power quality requirements
Advanced Protection: Complete safeguards including over voltage, over current, and short circuit protection
High Reliability: MTBF 50,000 hours with robust construction for continuous operation
User-Friendly Operation: VFD display with self-diagnosis and event memory functions
Application Areas
Our Ground Power Unit for Aircraft serves critical functions in aviation ground operations:
Commercial Airports: Powering aircraft during turnaround, maintenance, and boarding operations
Military Airbases: Supporting military aircraft maintenance and readiness operations
MRO Facilities: Aircraft maintenance, repair, and overhaul operations in hangars
Aircraft Manufacturing: Power supply during aircraft assembly and testing phases
Cargo Terminals: Supporting freighter aircraft operations and ground handling
Emergency Services: Providing ground power for emergency and medical aircraft
Our Services
Quality Control
Every Ground Power Unit for Aircraft undergoes exhaustive aviation-grade testing:
Component-level screening for aviation compliance
Full-load endurance testing for 48+ hours
Environmental testing from -20°C to 50°C operating range
Vibration and shock testing for mobile applications
Final certification against GJB572A-2006 and GJB181A-2003 standards
R&D Results
Our aviation power specialists have achieved significant advancements in Ground Power Unit for Aircraft technology:
Enhanced power density through advanced thermal management systems
Improved harmonic performance with 12-pulse rectification technology
Smart monitoring with predictive maintenance capabilities
Reduced acoustic noise for improved airport working environment
Modular design for easy serviceability and component replacement
Packaging and Transportation
We ensure secure delivery of every Ground Power Unit for Aircraft:
Heavy-duty export crating with custom shock absorption
Climate-controlled storage for sensitive electronic components
Comprehensive documentation including test certificates and manuals
Global logistics support with professional aviation equipment handling
After-Sales Service
We provide comprehensive support for all Ground Power Unit for Aircraft installations:
24/7 technical support for critical aviation operations
On-site commissioning and operator training programs
Preventive maintenance schedules and service contracts
Software updates and performance enhancements
Global spare parts network for minimum downtime
Qualification Certification
FAQ |
|---|
| Q1: What power outputs does your Ground Power Unit for Aircraft provide? |
| A: Our units provide simultaneous 115V/200V 400Hz AC power and 28.5VDC power, meeting standard aircraft requirements. |
| Q2: What aircraft types are compatible with your Ground Power Unit for Aircraft? |
| A: Our systems are compatible with most commercial, regional, and military aircraft including Boeing, Airbus, and regional jet models. |
| Q3: How quickly can the Ground Power Unit for Aircraft be deployed? |
| A: Our trolley-mounted units can be operational within minutes, with quick-connect aircraft connectors for rapid deployment. |
| Q4: What maintenance is required for your Ground Power Unit for Aircraft? |
| A: Regular maintenance includes filter cleaning, connector inspection, and performance verification. We provide detailed maintenance schedules and can offer service contracts. |
| Q5: Do your units include military interlocks for safety? |
| A: Yes, all our Ground Power Unit for Aircraft systems include 28VDC military interlock for enhanced safety during aircraft operations. |
Contact Us
For aircraft ground power solutions or technical specifications: acpower@acsoonpower.com , or submit your requirements using the form at the bottom of our website.
