Helicopter GPU
2. Input Voltage & Frequency: 3 Phase 380V, 50/60HZ
3. Output Voltage: 28.5V DC; Output Current: 750A continuously
4. Type: DC rectifier, mobile with trolley
5. Ingress Protection Grade: IP21
6. Applications: Drone
7. Brand: ACSOON (support OEM)
8. Features: Provides ground 28V DC power supply for drone onboard electronic equipment,High efficiency(≥93),High overload capacity(200% for 30S),Low noise during operation(less than 65dB within 1 meter)
- Product Description
Helicopter GPU: Power Your Aerial Operations with ACSOON
XI'AN JERRYSTAR INSTRUMENT CO., LTD is a leading manufacturer and supplier of high-quality helicopter GPUs. With over 15 years of experience, we've established ourselves as a trusted partner in the aviation industry. Our products stand out for their reliability, efficiency, and compliance with international standards. We pride ourselves on delivering cutting-edge power solutions that keep your rotorcraft operational in the most demanding conditions.
Why Choose ACSOON Helicopter GPUs?
When it comes to powering your helicopter's critical systems, you need a GPU you can trust. Here's why ACSOON is the right choice:
- Unmatched Reliability: Our products are built to withstand extreme conditions, ensuring consistent performance in any environment.
- Advanced Technology: We incorporate the latest innovations to deliver superior power quality and efficiency.
- Customizable Solutions: Our team can tailor our GPUs to meet your specific operational requirements.
- Global Compliance: ACSOON products meet or exceed international aviation standards, including MIL-STD-704F and EN61000-6-2:2005.
- Exceptional Support: Our dedicated after-sales team ensures you're never left without power.
Technical Specifications
| Feature | Specification |
|---|---|
| Input Three Phase | 200VAC (L-L), 208VAC (L-L), 380VAC (L-L), 400VAC (L-L), 415VAC (L-L) 440VAC (L-L) ±20% or customized |
| Frequency | 40 - 70HZ |
| Output Voltage | DC28.5VDC (24V-32V adjustable) |
| Output Amperes | 50A, 100A, 200A, 300A, 400A, 500A, 600A, 800A, 1000A |
| Voltage Regulation | +/-1% |
| Power Factor | ≧0.9 |
| Efficiency | ≧85% |
| Ripple | Less than 150mV, max 250mV (rms) |
| Display | VFD / LCD display (Voltage, Amperes, Power) |
| Overload Capacity | 125% for 10 min, 150% for 60s, 200% for 10s |
| Protections | O/V, Under Voltage, Current Limiting, Overheating, Short Circuit |
| Working Temperature | -10℃ to 50℃ |
| Humidity Tolerance | 10 - 95% |
| Altitude | ＜ 1800 meters |
| MTBF | 30,000 hours |
| MTTR | < 30 min |
| Standards Compliance | EN61000-6-2:2005, GJB152A-97, MIL-STD-704F |
Application Areas
Our products are versatile powerhouses, serving a wide range of sectors:
- Military and Defense: Powering mission-critical avionics and communication systems
- Emergency Services: Ensuring reliable operation for medical evacuation and search-and-rescue missions
- Law Enforcement: Supporting aerial surveillance and tactical operations
- Offshore Oil & Gas: Providing stable power for transport and inspection helicopters
- Firefighting: Enabling quick response times and extended operational capability
- VIP Transport: Ensuring smooth, uninterrupted power for luxury helicopter services
- Aerial Photography and Filming: Powering high-end camera equipment and stabilization systems
- Environmental Monitoring: Supporting long-duration flights for ecological surveys and climate research
- Agriculture: Powering crop-dusting and precision agriculture applications
- Utility Inspection: Enabling efficient power line and infrastructure surveys
Quality Control
At ACSOON, quality is our top priority. Our rigorous quality control process includes:
- Stringent component selection
- Multiple testing stages during production
- 100% burn-in testing before shipment
- Regular calibration of test equipment
- Continuous improvement based on customer feedback
R&D Results
Our commitment to innovation has led to several breakthroughs:
- Enhanced power density for lighter, more compact units
- Improved thermal management for extended operational life
- Advanced digital control systems for precise output regulation
- Modular designs allowing for easy upgrades and maintenance
Packaging and Transportation
We ensure your helicopter GPU arrives safely:
- Custom-designed shock-absorbing packaging
- Climate-controlled shipping containers
- Real-time tracking and monitoring
- Comprehensive insurance coverage
After-Sales Service
Our support doesn't end with delivery:
- 24/7 technical support
- Comprehensive warranty coverage
- On-site maintenance and repair services
- Regular software updates and performance optimizations
Qualification Certification
ACSOON is proud to hold:
- ISO 9001:2015 certification
- CE marking for European market compliance
- UL listing for North American safety standards
Exhibitions
Meet us at these upcoming events:
- Heli-Expo 2023
- Dubai Airshow 2023
- Singapore Airshow 2024
FAQ
Q: What's the typical lifespan of an ACSOON helicopter GPU?
A: With proper maintenance, our GPUs often exceed 10 years of service life.
Q: Can your GPUs handle extreme weather conditions?
A: Yes, our units are designed to operate in temperatures from -10°C to 50°C and up to 95% humidity.
Q: Do you offer customization for specific helicopter models?
A: Absolutely. We can tailor our GPUs to fit any rotorcraft's specific power requirements.
Q: What's your warranty policy?
A: We offer a standard 2-year warranty, with options for extended coverage.
Q: How quickly can you deliver replacement parts?
A: We maintain a global parts network, typically able to ship within 24 hours of a request.
Contact Us
Ready to power up your helicopter operations? Contact our sales team at acpower@acsoonpower.com for a personalized consultation.
