Low Frequency Inverter 48V

1.Input Voltage: 48V DC nominal (40-60V DC range)
2.Output Power: 1000VA to 5000VA capacity range
3.Output Voltage: 110V/120V/220V/230V/240V AC selectable
4.Output Frequency: 50Hz/60Hz fixed or 45-65Hz adjustable
5.Waveform Type: Pure sine wave output
6.Efficiency Rating: ≥88% at full load
7.Key Applications: Industrial equipment, telecommunications, backup systems
8.Brand: ACSOON (support OEM)
9.Core Features: Transformer-based design, high surge capacity, robust construction.

Send Inquiry Download

Product Description

XI'AN JERRYSTAR INSTRUMENT CO., LTD presents the reliable Low Frequency Inverter 48V, engineered for demanding industrial and commercial applications. Our Low Frequency Inverter 48V converts 48V DC power to clean AC power with exceptional reliability and surge capacity, making it ideal for powering sensitive equipment and motors in various operational environments.

Feature	Specification
Capacity (Single Phase Output)	1kVA - 200kVA
Capacity (Three Phase Output)	1kVA - 2000kVA
Input Voltage (Single Phase)	110-230VAC ±20%
Input Voltage (Three Phase)	200-440VAC ±20%
Input Frequency	50/60HZ or 40-70HZ
Output Voltage (Single Phase)	0-300Vac
Output Voltage (Three Phase)	0-520Vac
Output Frequency	50/60/100/200/400HZ or 40-800HZ adjustable
Frequency Regulation	≤0.1%
Voltage Regulation	±1%
Output VTHD	<3% @ Linear load
Response Time	≤2ms
Power Factor	≥0.8 (Standard), ≥0.9 (12 Pulse Optional)
Overall Efficiency	≥85%
Overload Capacity	125% for 60s, 150% for 30s
Working Temperature	-10°C to 50°C
Altitude	<1800m

Isolated output transformer,suitable for any unbalance loads, each single phase can be used independently
EMC compatible
Compatible with both 50Hz and 60Hz power supply network
Low harmonic distortion
Pure sine wave,sinusoidal output
Completely protection and alarm for over voltage, over current and overheating, etc
Display real-time data: voltage,current,frequency, power / power factor

ACSOON Low Frequency Inverter 48V delivers superior performance for critical power conversion needs:

High Surge Capacity: 300% surge capability for motor starting and inductive loads
Robust Construction: Industrial-grade components for long-term reliability
Pure Sine Wave: Clean power output compatible with sensitive electronics
Comprehensive Protection: Overload, short circuit, over temperature, and reverse polarity protection
Easy Integration: Multiple mounting options and straightforward installation

Our Low Frequency Inverter 48V serves essential functions across multiple sectors:

Industrial Automation: Powering control systems, motors, and machinery
Telecommunications: Base station power backup and equipment operation
Marine Applications: Boat and vessel power systems
Remote Sites: Off-grid power solutions for monitoring equipment
Emergency Systems: Backup power for critical infrastructure
Mobile Applications: Vehicle and transport equipment power

Quality Control

Each Low Frequency Inverter 48V undergoes rigorous quality validation:

Component-level testing and screening
Full-load endurance testing for extended periods
Thermal performance validation under maximum load
Safety certification to international standards
Final performance verification with calibrated equipment

R&D Results

Our engineering innovations in Low Frequency Inverter 48V technology include:

Enhanced transformer design for improved efficiency
Advanced cooling systems for better thermal management
Smart battery management algorithms
Reduced standby power consumption
Improved electromagnetic compatibility

Packaging and Transportation

We ensure secure delivery of every Low Frequency Inverter 48V:

Industrial-grade packaging with adequate protection
Custom packaging solutions for different models
Complete documentation including installation guides
Global shipping support with tracking services

After-Sales Service

We provide comprehensive support for all Low Frequency Inverter 48V installations:

Technical assistance for system integration
Installation guidance and commissioning support
Maintenance services and performance optimization
Remote troubleshooting capabilities
Operator training for optimal system use

FAQ
Q1: What is the advantage of a low frequency inverter compared to high frequency models?
A: Low frequency inverters offer higher surge capacity, better reliability, and longer lifespan, making them ideal for industrial applications.
Q2: Can your Low Frequency Inverter 48V power inductive loads like motors?
A: Yes, our inverter is specifically designed with high surge capacity to handle motor starting and other inductive loads.
Q3: What battery system is required for your Low Frequency Inverter 48V?
A: The inverter requires a 48V DC battery system with proper capacity based on your power requirements and backup time needs.
Q4: Does your inverter include battery charging capability?
A: Standard models are pure inverters, but we offer models with integrated battery chargers as an optional feature.
Q5: What is the typical efficiency of your Low Frequency Inverter 48V?
A: Our inverters typically achieve ≥88% efficiency across the operating range, with optimized performance at typical load levels.

For low frequency inverter solutions or technical specifications: acpower@acsoonpower.com , or submit your requirements using the form at the bottom of our website.
