Frequency Converter 50Hz to 60Hz Single Phase

1.Power Capacity: 1KVA to 30KVA single phase models
2.Input Specification: 220V/230V/240V, 50Hz single phase AC
3.Output Specification: 110V/120V/220V/230V/240V, 60Hz single phase AC
4.Frequency Stability: ±0.1% with crystal-controlled precision
5.Voltage Regulation: ±1% under varying load conditions
6.Conversion Efficiency: ≥90% with minimal power loss
7.Key Applications: International equipment operation, testing laboratories, commercial use
8.Brand: ACSOON (support OEM)
9.Core Features: Compact design, pure sine wave output, automatic voltage regulation

Send Inquiry Download

Product Description

Frequency Converter 50Hz to 60Hz Single Phase | Single Phase Power Frequency Conversion System

XI'AN JERRYSTAR INSTRUMENT CO., LTD presents the specialized Frequency Converter 50Hz to 60Hz Single Phase, designed to solve international power compatibility issues for single-phase equipment. Our Frequency Converter 50Hz to 60Hz Single Phase provides reliable frequency conversion with precise voltage regulation, enabling seamless operation of 60Hz equipment in 50Hz regions and vice versa.

Technical Specifications

Feature	Specification
Capacity (Single Phase Output)	1kVA - 200kVA
Capacity (Three Phase Output)	1kVA - 2000kVA
Input Voltage (Single Phase)	110-230VAC ±20%
Input Voltage (Three Phase)	200-440VAC ±20%
Input Frequency	50/60HZ or 40-70HZ
Output Voltage (Single Phase)	0-300Vac
Output Voltage (Three Phase)	0-520Vac
Output Frequency	50/60/100/200/400HZ or 40-800HZ adjustable
Frequency Regulation	≤0.1%
Voltage Regulation	±1%
Output VTHD	<3% @ Linear load
Response Time	≤2ms
Power Factor	≥0.8 (Standard), ≥0.9 (12 Pulse Optional)
Overall Efficiency	≥85%
Overload Capacity	125% for 60s, 150% for 30s
Working Temperature	-10°C to 50°C
Altitude	<1800m

Frequency Converter 50Hz to 60Hz Single Phase Main Features

Isolated output transformer,suitable for any unbalance loads, each single phase can be used independently
EMC compatible
Compatible with both 50Hz and 60Hz power supply network
Low harmonic distortion
Pure sine wave,sinusoidal output
Completely protection and alarm for over voltage, over current and overheating, etc
Display real-time data: voltage,current,frequency, power / power factor

Why Choose ACSOON Frequency Converter 50Hz to 60Hz Single Phase?

ACSOON Frequency Converter 50Hz to 60Hz Single Phase offers exceptional advantages for single-phase power conversion:

Precise Frequency Conversion: Accurate 50Hz to 60Hz conversion with ±0.1% stability
Wide Voltage Compatibility: Supports multiple input and output voltage configurations
Pure Sine Wave Output: Clean power with THD<3% for sensitive electronics
Compact and Portable: Space-saving design suitable for various environments
Comprehensive Protection: Overload, short circuit, and thermal protection systems

Application Areas

Our Frequency Converter 50Hz to 60Hz Single Phase serves diverse international power needs:

Residential Use: Operating 60Hz appliances in 50Hz regions
Commercial Equipment: Powering international retail and service equipment
Laboratory Testing: Equipment validation and compatibility testing
Medical Devices: Supporting international medical equipment operation
Audio-Visual Systems: Professional audio and video equipment compatibility
Industrial Controls: Single-phase motor and control system operation

Our Services

Quality Control

Each Frequency Converter 50Hz to 60Hz Single Phase undergoes rigorous quality validation:

Frequency accuracy and stability testing
Load performance testing with various equipment types
Thermal management validation under continuous operation
Safety certification to international standards
Final calibration with precision measurement instruments

R&D Results

Our technical innovations in Frequency Converter 50Hz to 60Hz Single Phase technology include:

Advanced DSP control for precise frequency generation
Enhanced power conversion topology for improved efficiency
Smart load adaptation for varying equipment requirements
Reduced electromagnetic interference for cleaner power output
Compact thermal management for reliable continuous operation

Packaging and Transportation

We ensure secure delivery of every Frequency Converter 50Hz to 60Hz Single Phase:

Industrial-grade packaging with adequate protection
Custom packaging solutions for international shipping
Comprehensive documentation including operation manuals
Global logistics support with professional handling

After-Sales Service

We provide comprehensive support for all Frequency Converter 50Hz to 60Hz Single Phase installations:

Technical assistance for application-specific configurations
Installation guidance and system commissioning
Maintenance services and performance optimization
Remote troubleshooting and diagnostic support
Operator training for optimal system utilization

Qualification Certification

FAQ
Q1: What types of equipment are compatible with your Frequency Converter 50Hz to 60Hz Single Phase?
A: Our converter is compatible with various single-phase equipment including appliances, power tools, laboratory instruments, and commercial equipment requiring specific frequency operation.
Q2: Can your converter handle motor starting currents for single-phase motors?
A: Yes, our converters are designed with sufficient surge capacity to handle motor starting currents and inductive loads.
Q3: What is the typical installation process for your Frequency Converter 50Hz to 60Hz Single Phase?
A: Installation is straightforward - simply connect input power, connect output to your equipment, and ensure proper grounding. Basic electrical knowledge is sufficient for installation.
Q4: How efficient is your frequency conversion process?
A: Our converters typically achieve ≥90% efficiency across the operating range, ensuring minimal energy loss during conversion.
Q5: What protection features are included for equipment safety?
A: Standard protections include over voltage, over current, short circuit, overload, and thermal protection with automatic shutdown features.
