120V AC To DC Rectifier
2. Power Rating: 12kW
3. Input Supply: AC Supply, Single / Three Phase, 50HZ-60HZ
4. Output Voltage & Current:120VDC, 100A
5. Type: DC Power Supply, DC Rectifier, Rack Mounted
6. Programmable: It can be connected with the PC through RSC232, RSC485 or LAN interface. On / Off time setup & Multiple groUPS of voltage and current values cycle test through PC control
7. Applications: Navigation Systems on Marine ship
8. Brand: ACSOON (support OEM)
9. Features:Electronics test on production line, electrical components aging, onboard battery power
- Product Description
XI'AN JERRYSTAR INSTRUMENT CO., LTD: Your Trusted 120V AC to DC Rectifier Manufacturer
At XI'AN JERRYSTAR INSTRUMENT CO., LTD, we specialize in manufacturing high-quality 120V AC to DC rectifiers. Our ACSOON brand power converters are designed to meet the diverse needs of industries like aviation, marine, and oil fields. With ISO 9001 certification and CE approval, we offer reliable, efficient, and customizable product solutions for your power conversion needs.
Technical Specifications: Model Series ADCW01
| Feature | Specification |
|---|---|
| Input | Single Phase or Three Phase + N + PE |
| Input Voltage | 220VAC (L-N) ±10%; 380VAC (L-L) ±10%, or customized |
| Frequency | 50HZ/60HZ |
| Output Voltage | 0 - Nominal Voltage adjustable |
| DC Voltage Options | 12V, 15V, 24V, 30V, 50V, 60V, 100V, 150V, 300V, 600V, or customized |
| Current | 0 - Nominal Current adjustable, with current limiting control |
| Current Options | 1A to 1000A, or customized |
| Voltage Stability | Line regulation ≤ 0.5% Nominal, Load regulation ≤ 0.5% Nominal |
| Ripple (RMS) | ≤ 0.5% Nominal Value |
| Power Control Mode | Potentiometer switch knobs, 1-byte resolution adjustment |
| Interface | Modbus Protocol RS232 (RS485), PC control for voltage/current setup and on/off |
| Display Accuracy | Voltage: Four and a half VFD, Resolution > 0.1V |
| Current: Four and a half VFD, Resolution > 0.1A | |
| Protection | Input phase loss, Output over voltage, overload current limiting, short circuit, over temperature |
| Cooling Mode | Air forced fan |
| IP Rating | IP20 (Customizable) |
| Color | RAL7035 |
| Working Temperature | -10°C to 45°C |
| Standards | EN61000-6-3 & EN60204-1 |
Application Areas
Industrial Automation、Renewable Energy Systems、Telecommunications、Automotive Manufacturing、Medical Devices、Consumer Electronics、Data Centers、Laboratory Equipment、Aerospace and Defense、Power Distribution Systems、Electric Vehicle Charging Stations、LED Lighting Systems、Battery Charging Systems、Welding Equipment、Electroplating and Surface Treatment
Quality Control
At ACSOON, quality is our top priority. We implement rigorous quality control measures:Strict component selection and testing、Multiple inspection points during production、100% functional testing before shipping、Regular calibration of testing equipment、Continuous improvement based on customer feedback
Why Choose ACSOON 120V AC to DC Rectifiers?
R&D Results
Our commitment to innovation has led to several breakthroughs:Improved efficiency up to 95%、Reduced size and weight by 30%、Enhanced EMI/EMC performance、Advanced thermal management solutions、Smart monitoring and control features
Packaging and Transportation
We ensure safe delivery of your 120V AC to DC rectifier:
Sturdy cardboard boxes with foam inserts
Palletized shipping for bulk orders
Customized packaging available for special requirements
Partnering with reliable logistics providers for global shipping
After-sales Service
Our commitment doesn't end with the sale:24/7 technical support、Comprehensive product documentation、Remote troubleshooting assistance、On-site support available (terms apply)、Regular firmware updates for compatible models
Qualification Certification
Our products and processes are certified by:
ISO 9001:2015 Quality Management System
CE Marking for European market compliance
UL Listing for North American market
RoHS Compliance for environmental standards
FAQ |
|---|
| Q1: What's the warranty on your products? |
| A: We offer a standard 2-year warranty, with extended options available. |
| Q2: Can you customize the output voltage and current? |
| A: Yes, we can tailor our rectifiers to your specific requirements. |
| Q3: How long is the typical lead time for orders? |
| A: Standard models usually ship within 2-3 weeks, while custom orders may take 4-6 weeks. |
| Q4: Do you offer volume discounts? |
| A: Yes, we provide competitive pricing for bulk orders. Contact our sales team for details. |
| Q5: Are your products compliant with international safety standards? |
| A: Absolutely. Our rectifiers meet or exceed global safety and EMC standards. |
Contact Us
Ready to upgrade your power conversion systems with our high-quality 120V AC to DC rectifier? Contact us today at acpower@acsoonpower.com for quotes, technical support, or to discuss your custom requirements.
