AC To DC Power Inverter
2. Power Rating: 11kW
3. Input Supply: AC Supply, Three Phase, 50HZ-60HZ
4. Output Voltage & Current:540VDC, 20A
5. Type: DC Power Supply, DC Rectifier, Rack Mounted
6. Programmable: It can be connected with the PC through RSC232, RSC485 or LAN interface. On / Off time setup & Multiple groUPS of voltage and current values cycle test through PC control
7. Applications: industial
8. Brand: ACSOON (support OEM)
9. Features:Electronics test on production line, electrical components aging, onboard battery power
- Product Description
AC to DC Power Inverter: Reliable Energy Conversion for Your Needs
Welcome to XI'AN JERRYSTAR INSTRUMENT CO., LTD, your trusted manufacturer and supplier of high-quality AC to DC power inverters. With over a decade of experience, we specialize in designing and producing top-tier power conversion solutions. Our ACSOON brand products are renowned for their reliability, efficiency, and versatility across various industries.
Technical Specifications
| Feature | Specification |
|---|---|
| Model Series | ADCW01 |
| Input | Single Phase or Three Phase + N + PE |
| Input Voltage | 220VAC (L-N) ±10%; 380VAC (L-L) ±10%, or customized |
| Input Frequency | 50HZ/60HZ |
| Output Voltage | 0 - Nominal Voltage adjustable |
| DC Output Options | 12V, 15V, 24V, 30V, 50V, 60V, 100V, 150V, 300V, 600V, or customized |
| Current | 0 - Nominal Current adjustable, with current limiting control |
| Current Range | 1A to 1000A, or customized |
| Voltage Stability | ≤ 0.5% Nominal (line and load regulation) |
| Ripple (RMS) | ≤ 0.5% Nominal Value |
| Control Interface | Modbus Protocol RS232 (RS485) |
| Display Accuracy | Voltage: Four and a half VFD, Resolution > 0.1V Current: Four and a half VFD, Resolution > 0.1A |
| Protection Features | Input phase loss, Output overvoltage, Overload current limiting, Short circuit, Over temperature |
| Cooling Method | Air forced fan |
| IP Rating | IP20 (Customizable) |
| Working Temperature | -10°C to 45°C |
| Standards Compliance | EN61000-6-3 & EN60204-1 |
Application Areas
Renewable Energy Systems、Electric Vehicle Charging Stations、Telecommunications Infrastructure、Industrial Automation and Control、Off-Grid and Backup Power Solutions、Marine and Offshore Equipment、Aerospace and Aviation Systems、Medical Equipment Power Supplies、Data Center and IT Infrastructure、Research and Laboratory Facilities
Quality Control
At XI'AN JERRYSTAR INSTRUMENT CO., LTD, quality is our top priority. We implement rigorous quality control measures throughout the production process:Stringent component selection and testing、Automated assembly lines with multiple inspection points、Comprehensive functional and stress testing、100% burn-in testing for enhanced reliability、Regular calibration of testing equipment
Why Choose ACSOON AC to DC Power Inverters?
R&D Results
Our commitment to innovation has led to several breakthroughs:
Enhanced efficiency algorithms for reduced power loss、Advanced thermal management systems
Intelligent power factor correction、Modular designs for easier maintenance and upgrades、Smart monitoring and remote diagnostics capabilities
Packaging and Transportation
We ensure the safe delivery of our AC to DC power inverters through:
Custom-designed protective packaging
Shock-absorbing materials for sensitive components
Climate-controlled shipping containers when necessary
Detailed handling instructions for logistics partners
Real-time tracking of shipments
After-Sales Service
We stand behind our products with comprehensive after-sales support:24/7 technical assistance、Warranty coverage on all inverters、Spare parts availability、On-site service for complex installations
Regular software updates and firmware upgrades
Qualification Certification
Our products meet international standards:
ISO 9001:2015 Quality Management System
CE Marking for European market compliance
UL Listed for North American safety standards
RoHS and REACH environmental compliance
EMC and LVD directive conformity
FAQ |
|---|
| Q1: What is the typical efficiency of your products? |
| A: Our inverters generally achieve efficiencies of 90-98%, depending on the model and operating conditions. |
| Q2: Can your inverters handle input voltage fluctuations? |
| A: Yes, our inverters are designed with wide input voltage ranges to handle fluctuations commonly seen in various power grids. |
| Q3: Do you offer customization for specific voltage or current requirements? |
| A: Absolutely! We specialize in tailoring our inverters to meet unique customer specifications. |
| Q4: What is the typical lead time for custom orders? |
| A: Lead times vary based on complexity, but we generally aim for 4-8 weeks for custom AC to DC power inverter orders. |
| Q5: Are your inverters suitable for harsh environments? |
| A: Many of our models are designed for rugged use, with options for enhanced environmental protection available upon request. |
Contact Us
Ready to elevate your power conversion capabilities? Reach out to our expert team at acpower@acsoonpower.com for personalized assistance and quotations.
