Environmental Proof GPU
2. Technology: Sealed solid-state frequency conversion
3.Input: 3-phase 400VAC ±15%, 50/60Hz auto-sensing
4.Protection: IP55 rated for harsh environments
5. Key Applications: Coastal airports, desert regions, extreme climate zones
6.Key Features: Weatherproof design; corrosion resistant; wide temperature operation; sealed connectors
7. Brand: ACSOON (environmental configurations available)
- Product Description
XI'AN JERRYSTAR INSTRUMENT CO., LTD manufactures durable environmental proof GPUs for operations in challenging climate conditions. Our systems are specifically engineered to withstand extreme environmental factors including salt spray, sand storms, heavy rain, and wide temperature variations, ensuring reliable aircraft ground power in the world's most demanding locations.
Technical Specifications
| Feature | Specification |
|---|---|
| Capacity (Three Phase Output) | 30kVA, 45kVA, 60kVA, 90kVA, 100kVA, 120kVA, 150kVA, 180kVA |
| Input Voltage (Three Phase) | 200Vac, 208Vac, 380Vac, 400Vac, 415Vac, 440VAC (L-L) ±20% |
| Input Frequency | 40 - 70HZ |
| Output Voltage (Three Phase) | 200VAC / 208VAC rated, 0-260Vac, 0-520VAC (L-L) |
| Output Frequency | 400HZ rated, 300HZ - 500HZ adjustable |
| Voltage Regulation | ±1% |
| Frequency Stability | ≤0.1% |
| VTHD | <2% |
| Power Factor | ≥0.8 (Standard), ≥0.9 (12 Pulse Optional) |
| Overall Efficiency | ≥85% |
| Overload Capacity | 125% for 10 mins, 150% for 60s, 200% for 30s, 400% for 1s |
| MTBF | 30,000 hours |
| Noise Level | <65dB at 1 meter |
ACSOON Environmental Proof GPU Main Features
- Auto voltage compensation system, ideal voltage at aircraft connector
- Self diagnose system which would show error code on digital display
- 10 events memory stores
- Pure sine wave, sinusoidal output
- Completely protection and alarm for over voltage, over current and overheating, etc
- Eco-friendly, lower power consumption with high efficiency
- With 28VDC military interlock
Why Choose ACSOON Environmental Proof GPUs?
ACSOON delivers reliable performance in extreme conditions:
Weather Resistant: IP55 protection against dust and water
Corrosion Proof: Special coatings for salt spray protection
Temperature Tolerant: Operation from -30°C to +55°C
Sealed Design: Protected against sand and dust ingress
Durable Construction: Long-lasting performance in harsh environments
Application Areas
Our environmental proof GPUs are essential for:
Coastal Airports: Salt spray environments
Desert Regions: Sand and dust protection
Tropical Areas: High humidity and rainfall
Arctic Operations: Extreme cold conditions
Military Bases: Deployment in harsh locations
Remote Airfields: Unprotected environments
Mining Operations: Dusty site requirements
Emergency Fields: Disaster response locations
Details display
Quality Assurance
Each environmental proof GPU undergoes extreme testing:
IP55 protection validation
Salt spray corrosion testing
Thermal cycling endurance
Sand and dust ingress testing
Environmental stress certification
Technical Features
Our environmental proof GPU incorporates:
Sealed enclosure design
Corrosion-resistant materials
Protected connection systems
Enhanced cooling with filters
Environmental monitoring
Packaging and Delivery
We ensure environmental protection:
Weatherproof packaging
Desiccant and vapor barriers
Careful climate-controlled shipping
Installation supervision
After-Sales Service
Environmental support package includes:
Climate-specific maintenance
Corrosion prevention services
Filter replacement programs
Emergency response
Environmental testing
Certifications
FAQ |
|---|
| Q1: What environments are environmental proof GPUs designed for? |
| A: Coastal, desert, tropical, and arctic conditions with extreme weather challenges. |
| Q2: What IP rating is provided? |
| A: IP55 protection against dust and water jets. |
| Q3: How is corrosion prevention achieved? |
| A: Special coatings and stainless steel components. |
| Q4: What temperature range is supported? |
| A: Operation from -30°C to +55°C. |
| Q5: Can systems handle sand and dust? |
| A: Yes, sealed design prevents ingress of fine particles. |
Contact Information
For technical specifications or operational solutions: acpower@acsoonpower.com ,or submit your requirements using the form at the bottom of our website.
