Industrial Programmable DC Power Supply
2. Topology: High-efficiency silicon carbide (SiC) technology
3. Input Voltage: 3-phase AC 400V±20%, 47-63Hz
4.Output Characteristics: 0-1000V / 0-500A (fully programmable voltage/current)
5. Applications: Battery formation & testing, electric vehicle research, power electronics validation
6. Ingress Protection Grade: IP21
7. Features: <0.05% regulation accuracy; bidirectional communication capability; master/slave parallel operation; regenerative energy recovery
8. Brand: ACSOON (support OEM)
9. Features: multiple history events memorized in record.
- Product Description
Industrial Programmable DC Power Supply | High-Accuracy Power Solutions for Manufacturing
XI'AN JERRYSTAR INSTRUMENT CO., LTD specializes in manufacturing advanced industrial programmable DC power supplies for demanding applications. With extensive experience in power electronics, we deliver precision solutions that meet rigorous industrial and research requirements. Our systems combine exceptional accuracy with robust performance, establishing us as a trusted partner for organizations worldwide that depend on reliable DC power sources.
Products Description
| Feature | Specification |
|---|---|
| Input | Single Phase or Three Phase + N + PE |
| 220VAC (L-N) ±10%; 380VAC (L-L) ±10%, or customized | |
| Frequency: 50HZ/60HZ | |
| Output Voltage | 0 - Nominal Voltage adjustable |
| DC 12V, 15V, 24V, 30V, 50V, 60V, 100V, 150V, 300V, 600V or customized | |
| Output Current | 0 - Nominal Current adjustable, with current limiting control |
| 1A to 1000A or customized | |
| Voltage Stability | Line regulation ≤ 0.5% Nominal |
| Load regulation ≤ 0.5% Nominal | |
| Ripple (RMS) | ≤ 0.5% Nominal Value |
| Interface | Modbus Protocol RS232 (RS485) |
| Display Accuracy | Voltage: Four and a half VFD, Resolution > 0.1V |
| Current: Four and a half VFD, Resolution > 0.1A | |
| Cooling Mode | Air forced fan |
| IP Rating | IP20 (Customizable) |
| Working Temperature | -10°C to 45°C |
Why Choose ACSOON Industrial Programmable DC Power Supplies?
ACSOON represents excellence in power conversion technology. Here's what distinguishes our systems:
Unmatched Precision: Delivers superior voltage and current regulation with minimal ripple noise、Wide Operational Range: Covers extensive voltage and current requirements for diverse applications、Energy Recovery Technology: Regenerative design returns energy to grid, reducing operating costs、Advanced Control Interfaces: Intuitive touchscreen, web server interface, and multiple protocol support、Global Certification Compliance: Meets international safety, EMC, and environmental standards
Application Areas
Our industrial programmable DC power supplies serve critical functions in:
Battery Manufacturing: Formation, testing, and grading of lithium-ion and other battery technologies、Electric Vehicle Development: Powertrain testing, battery pack simulation, and charging system validation、Industrial Automation: Powering servo drives, PLC systems, and industrial control equipment、Renewable Energy Research: Solar inverter testing, wind power system validation、Telecommunications: Powering base station equipment and backup power system testing、Aerospace and Defense: Avionics testing, satellite power system simulation、Research Institutions: Academic research, material science experiments, physics laboratories、Power Electronics Development: Testing of converters, inverters, and other power devices
These systems provide reliable performance where precision power delivery is essential for success.
Details display
01
Quality Assurance
Each industrial programmable DC power supply undergoes rigorous quality verification:Component-level screening and testing、Full-power thermal cycling and burn-in testing、Environmental stress testing under extreme conditions、Safety certification validation and compliance testing、Continuous production quality monitoring
02
Research and Development
Our R&D team drives innovation in industrial programmable DC power supply technology through:
Advanced digital signal processing implementation、Cutting-edge thermal management solutions、Enhanced communication protocol integration、Power density optimization techniques
03
After-Sales Service
Our comprehensive support includes:
24/7 technical support and troubleshooting、Scheduled maintenance and calibration services、Regular firmware and software updates、On-site training and operational guidance
、Worldwide spare parts availability
04
Certifications
Our products meet international standards including:
ISO 9001:2015 Quality Management System
CE, UKCA, RoHS, and REACH compliance
FAQ |
|---|
| Q1: What distinguishes an industrial programmable DC power supply from standard models? |
| A: Industrial versions offer higher power density, better accuracy, more robust construction, and advanced features necessary for demanding applications like battery testing and research. |
| Q2: Can multiple units be synchronized for higher power requirements? |
| A: Yes, our systems support master/slave parallel operation with automatic current sharing for power scaling up to several hundred kilowatts. |
| Q3: What communication interfaces are available? |
| A: Standard interfaces include Ethernet, USB, RS232/485, and optional GPIB or CAN bus. All interfaces support SCPI commands. |
| Q4: How does the regenerative energy recovery feature work? |
| A: When the unit operates in sink mode, it converts excess energy back to the grid with high efficiency, reducing energy consumption and heat dissipation. |
| Q5: Do you provide custom solutions for specific requirements? |
| A: Yes, we offer customized designs including special voltage/current ranges, form factors, and communication protocols. |
Contact Information
For detailed technical specifications or customized solutions, please contact us at: acpower@acsoonpower.com
